5ft Cross Flow Air Curtain
Original price was: ₨64,900.₨59,900Current price is: ₨59,900.
Product Highlights
Cross Flow Motor- Magnetic Auto Sensor
- 65% Energy Efficient
- Remote Control
Product Details
Product Details
Cross Flow Motor
The cross flow motor pushes air in an even sheet across the full 5ft opening instead of blowing hard in the middle and weak at the edges, so the barrier holds end to end and the unit runs quiet at 55 dB.
Remote Control
Turn it on, off, or adjust it from the remote, no reaching up to the unit and no manual switches at the door.
Magnetic Auto Sensor
A magnetic sensor tracks the door. Open it and the curtain kicks in, close it and it stops, so the barrier is there exactly when the doorway is open and nothing runs over a shut door.
65% Energy Efficient at 210W
The DAC-1315CF holds a 5ft barrier on just 210W. It keeps your conditioned air inside and outside air out, so your cooling or heating does less work and your bill stays lower.
3200 m³/h at 13 m/s
The curtain moves 3200 cubic meters of air per hour at 13 m/s, a strong enough stream to hold a clean barrier across a wide 5ft entrance in steady foot traffic.
Product Specifications
| Specification | Value |
| Length | 5ft |
| Model | DAC-1315CF / Y-MC |
| Type | Cross Flow |
| Power | 210W |
| Mount Height | Up to 11.5ft (3.5m) |
| Air Volume Flow Rate | 3200 m³/h |
| Air Speed | 13 m/s |
| Unit Size | 1500 x 185 x 220 mm |
| Net Weight | 16 kg |
| Voltage | 220 to 240V |
| Noise Level | 55 dB |
| Control | Remote + Magnetic Auto Sensor |
| Warranty | 1 Year (Official, Pakistan) |
FAQs
What is a 5ft Cross Flow Air Curtain used for?
It creates a protective air barrier across a doorway to keep dust, insects, smoke, and outdoor air from entering indoor spaces.
Where can the 5ft Cross Flow Air Curtain be installed?
It suits offices, retail stores, restaurants, clinics, supermarkets, and other commercial entrances where a clean, comfortable environment matters.
Does this air curtain help reduce energy costs?
Yes. It cuts the exchange of indoor and outdoor air, holding your indoor temperature steadier and easing the load on your heating and cooling systems.
Is the 5ft Cross Flow Air Curtain quiet during operation?
Yes. The cross flow motor gives smooth, consistent airflow at 55 dB for a comfortable working environment.
Can the air curtain run continuously throughout the day?
Yes. It is built for reliable long-run performance and can run continuously through business hours.
Does it turn on by itself?
Yes. The magnetic auto sensor activates the curtain when the door opens and stops it when the door closes.
